Alternator For Chevrolet Corvette 1997-2004 TG15C051, TG15S010; 400-40205

# 400-40205
Free Shipping on orders over $50
1 Year Warranty on all products
30 Day Returns for a full refund or replacement
Only $265.89
Retail $431.30

If you're having any issues at all with finding, buying, or receiving your part, please contact us.

Description
New Aftermarket Part From Total Power Parts

Applications:
MAKE TYPE MODEL YEAR ENGINE
ChevroletAuto and Light TruckCORVETTE1997350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette19975700cc RWD 5.7L V8
ChevroletAuto and Light TruckCORVETTE1998350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette19985700cc RWD 5.7L V8
ChevroletAuto and Light TruckCORVETTE1999350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette19995700cc RWD 5.7L V8
ChevroletAuto and Light TruckCORVETTE2000350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette20005700cc RWD 5.7L V8
ChevroletAuto and Light TruckCORVETTE2001350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette20015700cc RWD 5.7L V8
ChevroletAuto and Light TruckCORVETTE2002350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette20025700cc RWD 5.7L V8
ChevroletAuto and Light TruckCorvette20025736cc 5.7L V8
ChevroletAuto and Light TruckCORVETTE2003350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette20035700cc 5.7L V8
ChevroletAuto and Light TruckCorvette20035700cc RWD 5.7L V8
ChevroletAuto and Light TruckCorvette20035736cc 5.7L V8
ChevroletAuto and Light TruckCORVETTE2004350cu in 5.7L V8
ChevroletAuto and Light TruckCorvette20045700cc 5.7L V8
ChevroletAuto and Light TruckCorvette20045700cc 5.7L V8 Gas
ChevroletAuto and Light TruckCorvette20045700cc RWD 5.7L V8
ChevroletAuto and Light TruckCorvette20045736cc 5.7L V8
ChevroletAuto and Light TruckCORVETTE2005364cu in 6.0L V8
ChevroletAuto and Light TruckCorvette20055967cc 6.0L V8
ChevroletAuto and Light TruckCorvette20056000cc 6.0L V8
ChevroletAuto and Light TruckCorvette20056000cc 6.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2006364cu in 6.0L V8
ChevroletAuto and Light TruckCORVETTE2006427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20065967cc 6.0L V8
ChevroletAuto and Light TruckCorvette20065967cc 6.0L V8 Gas
ChevroletAuto and Light TruckCorvette20067011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20067011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2007364cu in 6.0L V8
ChevroletAuto and Light TruckCORVETTE2007427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20075967cc 6.0L V8
ChevroletAuto and Light TruckCorvette20075967cc 6.0L V8 Gas
ChevroletAuto and Light TruckCorvette20077011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20077011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2008378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2008427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20086200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20087011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20087011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2009378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2009427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20096200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20097011cc 7.0L V8
ChevroletAuto and Light TruckCORVETTE2010378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2010427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20106200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20107011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20107011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2011378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2011427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20116200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20117011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20117011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2012378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2012427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20126200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20127011cc 7.0L V8
ChevroletAuto and Light TruckCorvette20127011cc 7.0L V8 Gas
ChevroletAuto and Light TruckCORVETTE2013378cu in 6.2L V8
ChevroletAuto and Light TruckCORVETTE2013427cu in 7.0L V8
ChevroletAuto and Light TruckCorvette20136200cc 6.2L V8
ChevroletAuto and Light TruckCorvette20137011cc 7.0L V8
ChevroletAuto and Light TruckCorvette Convertible20035700cc 5.7L V8
ChevroletAuto and Light TruckCorvette Coupe20035700cc 5.7L V8
ChevroletAuto and Light TruckCorvette Hatchback20035700cc 5.7L V8
ChevroletAuto and Light TruckCorvette Z0620045700cc 5.7L V8

Specifications:
DescriptionAlternator
Volt12
Amps145
ConditionNew
Regulator Clock5:00
Rotation DirectionClockwise
Mount Hole ID 110.500mm
Mount Hole 1 TypeUnthreaded
Mount Hole 2 TypeUnthreaded
Mounting Ear Thickness2.008""
Mounting Ear Thickness51mm
Mounting Ear 2 Thickness2.008""
Mounting Ear 2 Thickness51mm
Fan LocationInternal
Regulator LocationInternal
Terminal ID 2B+
Terminal 2 SizeM8x1.25
Terminal ID 3S
Terminal 3 SizeSpade
Terminal ID 4F
Terminal 4 SizeSpade
Terminal ID 5L
Terminal 5 SizeSpade
PolarityNegative
Number of Grooves6
Groove OD2.610""
Groove OD66.300mm
Pulley TypeClutch
Pulley Outer Diameter2.831""
Pulley Outer Diameter71.900mm"

Please verify this is the right part number you need before ordering.
If you have questions, please email sales@totalpowerparts.com for fast friendly service.

Replaces these part numbers:
ArrowheadAVA0008
Delco334-1493
General Motors10305775A, 10305775B, 10350160, 10353440
Lester13969
Valeo2540073, 2542675, 2650164, 420164, 849032, TG15C013, TG15C051, TG15S010

Total Power Parts Alternators for Chevrolet and other GM Vehicles
Total Power Parts offers premium-quality alternators that deliver high-performance for Chevrolet and other General Motors brands such as Buick, GMC, Pontiac and Oldsmobile. Owners of Chevy cars, trucks, vans and SUVs appreciate the highly engineered quality of Total Power Parts alternators for flawless mechanical performance and longevity. Founded in 1911, Chevy has been a symbol of the American road for over a century. A Total Power Parts alternator is a great choice for keeping your Chevrolet or other GM vehicle on the road. (Check our applications table below for specific makes and models for this alternator.)

With Total Power Parts alternators, you'll get:

  • Superior Quality Every Time - Our aftermarket alternators deliver performance that's equivalent to the original.
  • Direct-Fit OEM Replacement Parts - Total Power Parts aftermarket alternators are designed for perfect fitment to replace the ones that originally came with your vehicle.
  • Engineer-Tested Excellence - Our alternators go through a rigorous testing program to ensure optimal performance. Most alternators are supplied with their final test results and performance curve.

Reasons to choose Total Power Parts for your next alternator:

  • Built to Take the Heat - Most Total Power Parts alternators offer high-temperature epoxy, heavy-duty rectifiers, high-quality regulators, top-quality bearings and high-temperature grease produce better charging and longer life under high-heat environments.
  • Brand New Alternator - Never settle for a secondhand one. Many places will try to sell you a used alternator for about the price we'll sell you a new one.

The Total Power Parts Advantage - Factory-Direct Pricing and 1-Year Warranty
Total Power Parts sells its exceptional-quality electrical components at low factory-direct prices. Total Power Parts delivers exceptional value for products that we stand behind with our total-confidence 1-year warranty. Yes, you have a full year to make sure your alternator meets your expectations.


Warranty
All of our products are covered by our one year warranty from date of purchase. If you have a problem, we will take every step to assist you.
