Description
| New Aftermarket Part From Total Power Parts |
| Applications: | |||||
|
| Specifications: | |
| Unit Type | Alternator |
| Voltage | 12 |
| Rotation | CW |
| Dimension | Replacement 10SI Unit:, Mtg. Ear Top Holes: (3) x 5/16-18 Threaded, Mtg. Ear Bottom Hole: 12.9mm Unthreaded, Mtg. Ear Top Thick: 11.2mm, Mtg. Ear Bottom Thick: 26.2mm, B+ Terminal: 12-24, Note: 1-Wire, |
| Amperage | 63 |
| Clock | 12 |
| Pulley Class | V1 |
| Regulator | IR |
| Fan Type | EF |
| Fits | Marine Applications 1-V Pulley 66.7mm OD Use Spacer 550352 IF Additional One Inch Foot IS Required This is a 10SI Style Alternator Used to Replace the Motorola Units With a 1 Inch Bottom Mounting Foot and a 1-Wire Hook-up in Marine Applications.: See Also ADR0397 (Higher Amp): See Also ADR0398 (2-Wire Hook-up) |
| Please verify this is the right part number you need before ordering. If you have questions, please email sales@totalpowerparts.com for fast friendly service. |
| Replaces these part numbers: | |
| API MARINE | 20091 |
| ARCO MARINE | 20500 |
| ARROWHEAD | ADR0396 |
| EMP PARTS | 4-1064XMP |
| J & N | 400-20004 |
| LESTER | 8904 |
| WAI | 8904N |
Total Power Parts Alternators Five reasons to rely on Total Power Parts for your next alternator:
Backed by a Road and Trail-Worthy 1-Year Warranty : |
All of our products are covered by our one year warranty from date of purchase. If you have a problem, we will take every step to assist you.
