| New Aftermarket Part From Total Power Parts |
| Applications: |
| MAKE |
TYPE |
MODEL |
YEAR |
ENGINE |
| John Deere | | 5720 | | JD 4-276 80HP Dsl | | John Deere | | 5720 | | | | John Deere | | 5820 | | JD 4-276 88HP Dsl | | John Deere | | 5820 | | | | John Deere | | 6020 | | All | | John Deere | | 6020 | | | | John Deere | | 6120 | | JD 4-276 80HP Dsl | | John Deere | | 6120 | | | | John Deere | | 6215 | | JD 4-276 Dsl | | John Deere | | 6215 | | | | John Deere | | 6220 | | JD 4-276 90HP Dsl | | John Deere | | 6220 | | | | John Deere | | 6320 | | All | | John Deere | | 6320 | | | | John Deere | | 6415 | | All | | John Deere | | 6415 | | | | John Deere | | 6420 | | All | | John Deere | | 6420 | | | | John Deere | | 5510N | | JD 4-276 89HP Dsl | | John Deere | | 5510N | | | | John Deere | | 6120L | | JD 4-276 80HP Dsl | | John Deere | | 6120L | | | | John Deere | | 6220L | | JD 4-276 90HP Dsl | | John Deere | | 6220L | | | | John Deere | | 6320L | | All | | John Deere | | 6320L | | | | John Deere | | 6420L | | All | | John Deere | | 6420L | | | | John Deere | | 6520L | | All | | John Deere | | 6520L | | |
|
| Specifications: |
| Description | Starter |
| Family | Letrika/Mahle AZF42 |
| Volt | 12 |
| Power | 3.400 kw |
| HP | 4.559 |
| Rotation Direction | Clockwise |
| Electric Starter Type | Planetary Gear Reduction (PLGR) |
| Number Of Teeth | 10 |
| Gear OD | 1.260"/32mm |
| Mount Hole ID 1 | 11mm |
| Mount Hole 1 Type | Unthreaded |
| Mount Hole 2 Type | Unthreaded |
| Mounting Ear Distance 1 | 105.300mm/4.146" |
Please verify this is the right part number you need before ordering.
If you have questions, please email sales@totalpowerparts.com for fast friendly service. |
| Replaces these part numbers: |
| Arrowhead | IS1300 |
| Bosch | 1230003 |
| J&N Electrical Products | 410-24100 |
| John Deere | RE506589, RE71505 |
| Lester | 18363 |
| Mahle | 11.131.883, IS1300, MS419 |
Warranty
All of our products are covered by our one year warranty from date of purchase.
If you have a problem, we will take every step to assist you.
